Our Services:

Steel Detailing

• We have 15 Tekla Licenses, 40 detailers working over 3 shifts. We use Advance Steel and Tekla as primary tools. We will not stuff you around with unnecessary RFIs, wrong submissions. We take care to see that steel can be fabricated and can be installed. Our minimum checks are very comprehensive and will save you a ton of time and money. While we may not be the cheapest in terms of the initial quote, we are confident we would be the cheapest for you in the final analysis. Try us for your next job
• Precast Panel Detailing
  • We use a combination of tools to get you to error-free Precast drawings. A 3d model is created to generate a marking plan and elevations. All shop drawings are in 2d Autocad. 3d model is not part of deliverables.

• Material Take Off (Estimation of steel in your projects)
  • From Structural PDF files, we create a stick model using Autocad. We then use an in-house API to convert the 2d Autocad drawing to a 3d Tekla model. Connection plates and Base plates are not modeled for base level take off. The delivery is a 3d IFC model, material list, KISS/Strumis file
• Structural Drafting (A service to Structural Engineers)
  • We produce full set of structural drawing from structural engineers sketches. The deliverables are full set of structural drawings, due diligence on whether there are issues with structural design, details, sections member schedules, CAD files, pdf files. We take the monkey work out as well as add value. However, we do not do calculations. If you provide loading conditions we can provide you a staad pro model.
• MetalWorks detailing (Steel Detailing)
  • With our experience in Facades, Balustrades (Stainless and Glass), Screens you will not go wrong if you choose us. We look at everything which is required to do a successful fabrication and install. Takes care of Architects intent.

 Our History

Tek1 Pty Ltd was established in 2008 as a drafting house. We started with just one employee and focused on just precast and steel detailing. Since that time we have grown significantly – we now employ over 40 full-time staff in our steel detailing office, and about a dozen more in our precast division.
