Footings are the foundation elements that transfer the load from the structure to the ground ensuring stability and strength. Choosing the appropriate type of footing is crucial for the overall safety and performance of the building. Failure in ensuring appropriate footing is used or the if the footing lacks in strength or stability leads to the building to settle unevenly, develop cracks, tilt, and even face catastrophic failure. This jeopardizes safety and results in expensive repairs.

Commonly used types of Footings:

1. Strip Footing:

Strip footings provide support for a row of columns or a continuous load-bearing wall. They are ideal for structures with a even distribution of load along a straight line. These are commonly used alongside steel framing.

2. Isolated Footing:

Isolated footings, also known as pad footings, are designed to support single columns. These are usually square, rectangular, or circular pads that provide stability for light to moderate loads.

3. Combined Footing:

When steel columns are spaced closely, combined footings serve as an efficient foundation. They prevent overlapping of individual footings and ensure stability under heavy loads.

4. Strap Footing:

Strap footings connect isolated footings with a concrete beam. This strap beam transfers the load from a heavily loaded column to a less loaded column, balancing the pressure on the soil . This is particularly useful for unevenly spaced steel columns.

5. Stepped Footing:

Stepped footings are ideal for sloped sites or uneven terrain. The steps help in maintaining level support for columns and walls while minimizing excavation.

6. Raft Footings:

Raft footings also known as mat footings are large, thick concrete slabs that support the entire building footprint, distributing loads evenly across the foundation area. They are particularly useful in steel structures with high loads or poor soil conditions.

7. Pile Footings:

Pile footings are deep foundations used when surface soil cannot support the structure. Piles are driven deep into the ground to reach more stable soil layers or bedrock.

Factors for choosing the correct type of footing :

• Soil Condition: The bearing capacity and stability of the soil determine which footing is suitable.
• Load Requirements: The weight and distribution of the building’s load help decide the footing size and type.
• Building Type: The design and purpose of the structure influence the selection of footing.
• Space Availability: The available space for construction can necessitate certain footing types over others.
• Budget Constraints: Cost considerations can affect the choice of footing material and design.
• Environmental Factors: Local climate, water table level, and seismic activity are also important considerations.

Sources :

5 Types of footing – Best footing – Images – Uses [PDF] – Definecivil

Types of footing Used in Building Construction (7 Different Types) (constructionor.com)

What is Grating:

Metal grating is a framework made from metal bars, plates or mesh arranged in a grid pattern. It allows for the passage of light, air and water while providing a strong platform.

Types of Gratings:

1. Bar Grating:

Bar grating is composed of a series of parallel bars joined by perpendicular crossbars connected using methods like welding, riveting, or press-locking. Bar grating is the most common type of metal grating.

2. Expanded Metal Grating:

Expanded metal grating created by cutting and stretching a sheet of metal, resulting in a mesh with diamond-shaped openings. The resulting diamond-shaped pattern creates a slip-resistant surface.

3. Wire Mesh Grating:

Wire Mesh Grating is produced by using rows and columns of intersecting steel wires forming a grid-like pattern. This grating offers excellent load-bearing capacity due to its grid structure.

4. Safety Grating:

Safety grating features a serrated or perforated surface that is created by forming and punching the grating. The primary function of safety grating is to prevent slips and falls, especially in wet or oily conditions.

Functionality of Metal Grating:

1. Structural Support: Metal grating provides a strong and stable platform, capable of supporting significant weight. It’s commonly used in walkways, platforms, and mezzanines.
2. Drainage and Ventilation: The open design of metal grating allows for efficient drainage and airflow, making it ideal for outdoor applications and environments requiring ventilation.
3. Safety: Specific types of grating, such as safety grating, offer enhanced slip resistance, which is crucial in preventing accidents in wet or oily conditions.
4. Weight Reduction: Metal grating offers a high strength-to-weight ratio, making it an excellent choice for applications where minimizing weight is essential.
5. Corrosion Resistance: Grating made from materials like stainless steel or aluminum is highly resistant to corrosion, suitable for use in harsh environments.

Applications of Metal Grating

1. Industrial Flooring: Metal grating is extensively used in factories, warehouses, and plants, providing durable and safe flooring solutions.
2. Drain Covers and Trench Grates: The open structure of metal grating makes it perfect for covering drains and trenches, allowing water to pass through while keeping debris out.
3. Stair Treads: Metal grating is often used for stair treads, providing a non-slip surface that enhances safety in both indoor and outdoor staircases.
4. Marine and Offshore Platforms: The durability and corrosion resistance of metal grating make it suitable for marine environments, where it is used on ships, offshore platforms, and docks.
5. Public Infrastructure: Metal grating is used in various public infrastructure projects, including pedestrian bridges, park benches, and street furniture.

Sources :

What is Metal Grating? Types and Uses of Metal Gratings – What Is Piping

Commonly used stairs in Australia:

1. Straight Stairs:

Straight stair consists of a single stair flight from lower to upper level. Straight stairs are the most common type of stair used in residential, commercial and industrial buildings not just in Australia but all over the world as it is easy to design and build.

Stair Flight: It refers to a series of steps or a staircase that leads from one level or floor to another.

2. L-Shaped stairs:

L-Shaped stair consists of 2 stair flight which bends by 90° at the landing forming a L shape. It is used when staircase is needed to fit in the corner of the building. It is more visually appealing than straight stairs.

Landing: A Stair landing is a level platform found at the top, bottom or in the middle of the stairs. An Intermediate landing acts as connecting platform between two stair flights.

3. U-Shaped stairs:

U-Shaped stair consists of 2 stair flights which bends by 180° at the landing forming a U shape. It is commonly used in multistory buildings.

4. Winder Stairs:

Winder Stair is similar to L-shaped stair and U-shaped stair, but here the landing is replaced by triangular or trapezoidal steps. It is commonly used in older homes or used as a secondary stair.

5. Spiral Stairs:

Spiral Stairs have a circular or helical shape with stair flight winding around a central pole or column. It is commonly used in space-constrained areas and as outdoor stairs. Spiral stairs can be challenging to use for people with mobility issues.

6.Curved Stairs:

Curved Stair’s stair flight follows a curved or circular path. Curved stairs are mostly used for its aesthetic appeal rather than functionality. Curved stairs can be challenging to use for people with mobility issues.

7.Floating Stairs:

Floating Stairs are also known as cantilever stairs. These stairs are anchored to the wall on one side while leaving out the other side support less, thus creating an illusion of floating. Floating stairs are used where minimalistic design is desired by the architect.

Sources:

Staircase Building Regulations: Our Comprehensive Guide (adara.co.uk)

STAIRCASE TERMINOLOGY | An Architect Explains | ARCHITECTURE IDEAS

What is Lightweight framing:

Lightweight framing is a construction technique that utilizes lightweight materials, such as timber or metal studs which are lighter than traditional construction materials like bricks and concrete to create a structural framework for a building. Lightweight framed construction is the most common construction system used in Australia.

How does lightweight framing work:

Lightweight framing is a construction method where a building’s structural framework is built using materials like timber or light gauge steel, which are both strong and light. The process involves assembling closely spaced vertical studs, horizontal joists, and sloping rafters, which are then fastened together using specialized fasteners, such as screws or self-tapping rivets to form the skeleton of the building. This frame holds up exterior wall claddings, internal linings, flooring, roofing, windows and doors.

Studs: vertical framing members that form the primary structural support for walls in buildings.

Joists: horizontal framing members that support the floors and ceilings of buildings.

Rafters: Rafters are sloped framing members that support the roof covering of a building.

Advantages of Lightweight framing:

• Lightweight and easy to handle: Lightweight framing is not heavy, making it simpler for workers to move and work with, which can help speed up building projects.
• Resistant to pests and decay: Steel and termite proofed timber frames doesn’t attract bugs like termites and won’t rot over time, which helps keep buildings in good shape for longer.
• Faster construction process: Building with lightweight steel frames can be done more quickly than with traditional wood framing, allowing for faster completion of structures.
• Recyclable and sustainable: This type of framing can be melted down and made into new products, which is good for the planet because it means less waste.
• Reduces foundation load: Since it’s not as heavy as other building materials, it puts less stress on the building’s base, which can mean a lighter and less costly foundation is needed.

Disadvantages of Lightweight framing:

• Less noise insulation than wood: Lightweight frames don’t block sound as well as wood does, which means you might hear more noise from outside or other rooms.
• Can corrode over time: If the metal isn’t treated properly, it can rust or wear away, especially in places where there’s a lot of moisture or salt in the air.
• Not as strong for heavy loads: These frames might not hold up as well under very heavy weights, like big furniture or multiple floors, compared to other building materials.
• Difficult to modify once installed: Once you put up a metal frame, it’s harder to change things around, like adding a door or window, because the metal is tough to cut through.
• Conducts heat, poor insulator: Lightweight framing have poorer thermal insulation properties compared to heavier materials. It fails to effectively retain warmth during winter or keep cool air in during summer, which can lead to higher energy bills.

Common structures where lightweight framing is used are:

• Residential Construction
• Commercial Buildings
• Industrial Facilities
• Institutional Buildings
• Modular Construction
• Renovation and Retrofitting

Sources:

www.yourhome.gov.au/materials/lightweight-framing

While working on a project, I noticed the structural design showing a truss structure on a roof.

What are Roof Trusses:

Roof trusses are engineered timber or metal frameworks that provide support for the roof covering materials and often the ceiling materials below. They are designed to span large distances without the need for internal load-bearing walls, allowing for more open and flexible floor plans.

Advantages of Roof Trusses

• Strength and Stability: Roof trusses are engineered to withstand heavy loads, ensuring the structural integrity of a building even under adverse conditions such as strong winds or heavy snowfall.
• Versatility: With various designs available, roof trusses can accommodate a wide range of architectural styles and building requirements, from residential homes to commercial complexes.
• Cost Efficiency: Prefabricated roof trusses are manufactured off-site to precise specifications, reducing construction time and labor costs compared to traditional stick-built roof framing methods.
• Space Optimization: Certain truss designs, such as scissor trusses and attic roof trusses, allow for increased ceiling height and attic space, enhancing the functionality and aesthetic appeal of a building’s interior.

Disadvantages of Roof Trusses:

• Repair Difficulty: If damaged, trusses can be more difficult to repair compared to conventional framing because of their integrated design.
• Customization Limitations: Because trusses are mass-produced in factories, finding a truss that perfectly matches the unique dimensions of a specific project can be challenging
• Long Lead Times: The manufacturing process for trusses can lead to longer lead times, which may delay construction schedules.
• Aesthetic Considerations: Some may find trusses less aesthetically pleasing than traditional roofs because they tend to be made out of large, bulky pieces of wood.

Types of Roof Trusses:

1. King Post Truss: Among the simplest truss designs, the king post truss features a central vertical post (the king post) supporting horizontal beams extending outward to either side, forming a triangular shape. This type is commonly used in smaller structures or for decorative purposes.

2. Queen Post Truss: Similar to the king post truss but with two vertical posts (queen posts) instead of one, this design offers increased stability and is often used in larger roof spans.

3. Scissor Truss: Scissor Trusses are designed with sloping bottom chords that intersect at a central point, creating a scissor-like shape. This design provides additional height and openness to the space below, allowing for open planned living or commercial spaces with a vaulted or cathedral ceiling.

4. Attic Roof Truss: Attic Roof Trusses are a modified version of the king post truss design that includes a room-like space within the roof. This type of truss is ideal for creating additional living space or storage within a roof without needing an additional level or more land space.

5. Fink Roof Trusses: Fink Roof Trusses consist of a network of triangles that distribute the load evenly across the structure, providing maximum strength and stability allowing for long spans that are often utilized in commercial buildings.

6. Flat truss: Flat Trusses are used in flat or low-pitched roofs often where there are building height limitations due to council regulations, overhanging trees or architectural requirements.

Where are roof trusses used:

Roof trusses are used in a wide variety of construction projects, ranging from residential homes to commercial buildings and industrial structures. Here are some common places where roof trusses are employed:

• Residential Homes
• Commercial Buildings
• Industrial Facilities
• Educational Institutions
• Recreational Facilities
• Agricultural Buildings
• Religious Buildings

Sources:

Types of Roof Trusses and Their Applications in Residential Design | ClearCalcs

While discussing steel-to-concrete connections with the team leader, he mentioned shear studs during the conversation.

What is a shear stud :

A shear stud is a fastener which provides structural connection between concrete slabs and steel support beams. It is typically a steel pin or grommet that extends out of the top flange of a steel beam. They are typically made of steel.

How does it work :

• After the metal decking is installed over the structural steel, a spot welder is used to weld the shear studs onto the steel beam. These studs are typically evenly spaced along the beam.
• Once the shear studs are in place, a concrete slab is poured onto the steel beam. The concrete flows over the metal decking and surrounds the shear studs, covering them.

• As the concrete hardens, it adheres to the shear studs. But it’s not just the concrete holding onto the studs; the studs also grip the concrete. This grip is due to friction. They ensure that the steel beam and the concrete slab act together as one robust unit. The rough surface of the shear studs creates friction with the concrete, making it difficult for the concrete to slide off the studs.
• When a force, such as wind pushing on the building or people walking on the floor, exerts pressure on the steel beam, the studs transfer this force back to the concrete slab through frictional resistance.

Shear studs are commonly used in :

• Composite Steel Construction
• High-Rise Buildings
• Bridges and infrastructure projects
• Infrastructure rehabilitation projects

Sources :

smdltd.co.uk

www.shearstudwelding.com

help.scia.net

While working on a project, the structural details of an engineering drawing showed the incorporation of sag rods with purlins and braces.

What is a Sag Rod?

A sag rod is a tension member designed to minimize sagging or deflection by providing tensile support and reinforcement in horizontal structural elements such as roof trusses or purlins. Sag rods are typically fabricated from high-strength steel alloys, such as carbon steel or stainless steel.

How does it work?

Sag rods are positioned between purlins or girts along the length of the structure. Once the sag rods are in place, they are tensioned by tightening the nuts on the threaded ends of the rods until the desired tension is achieved, stabilizing and effectively distributing loads within the structure.

Structures where sag rods are commonly used :

• Roof Structures
• Bridge Construction
• Canopies and Awning Structures
• Seismic Retrofitting

Sources:

https://constancelee.en.ec21.com/

While discussing bolts and washers for a connection detail with the team leader, he mentioned DTI washers in the conversation.

What is DTI Washer?

DTI washers, also known as load indicating washers or torque control washers, are specialized washers designed to provide a visual indication of bolt tension during the tightening process. They feature convex ridges that contain small pockets of bright orange silicone.

How does it work:

DTI washers are installed the same way as normal washers. During tightening, the ridges resist until the required compression is achieved. At that point, the ridges compress and force the silicone out of the cavity. This allows the erector to immediately know if bolts are tightened to the correct tension, eliminating the need for gauges or extra measures to ensure tightness.

Where is it used:

DTI washers are used in connections where specific tension levels are needed. They are commonly used in various applications, including:

• Bolted Connections in Structural Steel Frames
• Bridge Construction
• Steel Roof Truss Systems
• Steel Plate Girder Bridges
• Steel Pipe Supports and Hangers

Sources:

https://www.thesteelsupplyco.com/blog/direct-tension-indicator-washers

https://www.vihasteel.com/dti-washer-direct-tension-indicator.html
